IGBT module inverter technology and digital control system are adopted to ensure accurate and reliable control;
One machine has multiple functions, including DC pulse chlorine arc welding, DC chlorine arc welding, AC pulse chlorine arc welding, AC chlorine arc welding, manual arc welding and so on;
The front panel layout is designed in accordance with the principle of standardized operation process, with humanized overall operation and convenient and fast parameter adjustment;
It has the functions of slow current rise, slow current drop, pulse frequency, early air supply and delayed air cut-off, especially suitable for automatic welding;
Wide range of welding materials, suitable for the welding of low carbon steel, stainless steel, alloy steel, red copper, aluminum, aluminum magnesium alloy and other materials.
Product model |
TIG-315 AC DC |
TIG-500 AC DC |
Rated input voltage |
3PH380V |
3PH380V |
Power frequency |
50/60HZ |
50/60HZ |
Rated input current |
21A |
40A |
Rated input power |
13.8KVA |
26KVA |
External fuse |
40 |
60 |
No load voltage |
85V |
95V |
welding current |
15-315A |
20-500A |
Rated load duration |
60% |
60% |
Efficiency (at rated conditions) |
≥0.85 |
≥0.85 |
Insulation class |
F |
F |
Enclosure protection class |
IP21S |
IP21S |
Overall dimension |
515X275X465mm |
1040X515X970 mm |
weight |
25Kg |
95Kg |
