It has overvoltage and overcurrent protection functions;
Adopt advanced inverter technology, small volume and light weight;
High frequency pressurized arc striking, good arc starting performance and stable arc during welding;
Unique output characteristic design, more suitable for wire filling welding, beautiful weld;
It can be widely used in petroleum, chemical industry, power construction, metallurgy, chemical construction, boiler, pipeline and other manufacturing industries;
It is suitable for welding all positions of low carbon steel, cast iron, stainless steel, copper alloy, aluminum alloy, etc.
Product model
|
TIG-200 |
TIG-250 |
TIG-315 |
TIG-400 |
Rated input voltage |
AC220V±15% |
AC220V±15% |
AC380V±15% |
AC380V±15% |
Power frequency |
50/60 |
50/60 |
50/60 |
50/60 |
Rated input power(kva) |
3.4 |
4 |
9.3 |
18.8 |
No load voltage |
60 |
60 |
60 |
60 |
Output current regulation(A) |
10-200 |
10-250 |
10-315 |
10-400 |
Load duration(%) |
60% |
60% |
60% |
60% |
Degree of protection |
IP21S |
IP21S |
IP21S |
IP21S |
efficiency(%) |
80% |
80% |
80% |
80% |
Insulation class |
F |
F |
F |
F |
Overall dimension |
360X170X295mm |
360X170X295mm |
470X220X360mm |
510X240X410mm |
weight |
7.3kg |
7.3kg |
11.6kg |
22kg
|
