CWCS

Solid wire

Typical application: shipbuilding, offshore, bridge, pressure vessel, and general fabrication

Product Details

Model: 7229929000

Typical application: shipbuilding, offshore, bridge, pressure vessel, and general fabrication.

Overview

Quick Details

Warranty:: 1 year

Customized support:: OEM

Place of Origin:: Jiangsu, China

Brand Name:: FUERMU

Model Number:: ER70s-6

Material:: Carbon and High Tensile Steel, Stainless Steel Solid Wire

Diameter:: 0.8/0.9/1.0/1.2/1.4/1.6-2.0mm

Melting Point:: standard, International Standard

Weight:: 15 kg/box

Application:: Ships,Bridges,Buildings,Pipes, Pressure vessels, offshore, steel construction, railway construction, pressure vessel

Flux Content:: standard

Yield Strength(Mpa):: 460

Tensile Strength(Mpa):: 570

Elongation(%):: 31

Impact value J(℃):: 64/-30

Name:: ER70s-6 CO2 Welding Wire

OEM:: Accept

Approval:: ABS,LR,BV,GL,DNV,KR,CCS

Certification:: CE, ISO, CCS, ABS, GL.DNV, LR, BV, NK, RINA, NAKS

Supply Ability

Supply Ability: 500 Ton/Tons per Month

Packaging & Delivery

Packaging Details

vacuum packaging
15 kg/ spool;
1 spool/ ctn;
72 ctns/ pallet

Port

Shanghai, China

Picture Example:

Lead Time:

Quantity(Kilograms)	1 - 50000	>50000
Est. Time(days)	15	To be negotiated

Category		AWS standard	Chemical compostition of deposited metal(wt%)
Category		AWS standard	C	Mn	Si	Cr	Ni	Mo	P	S	Cu
Carbon Steel and High Tensile Strength Steel	Gas Shield	ER70S-6	0.072	1.41	0.82	0.02	0.01	0.01	-	-	-
		ER80S-G	0.68	1.43	0.51	0.07	0.06	0.41	-	-	-
		ER110S-G	0.052	1.65	0.32	0.03	2.26	0.32	-	-	-
Stainless Steel	CO2 Gas Shield	ER308	0.08	1.0-2.5	0.30-0.65	19.5-22.0	9.0-11.0	0.75	0.03	0.03	0.75
		ER308L	0.03	1.0-2.5	0.30-0.65	19.5-22.0	9.0-11.0	0.75	0.03	0.03	0.75
		ER309	0.12	1.0-2.5	0.30-0.65	23.0-25.0	12.0-14.0	0.75	0.03	0.03	0.75
		ER309L	0.03	1.0-2.5	0.30-0.65	23.0-25.0	12.0-14.0	0.75	0.03	0.03	0.75
		ER316L	0.03	1.0-2.5	0.30-0.65	18.0-20.0	11.0-14.0	2.0-3.0	0.03	0.03	0.75
		ER347	0.08	1.0-2.5	0.30-0.65	19.0-21.5	9.0-11.0	0.75	0.03	0.03	-
		ER385	0.025	1.0-2.5	0.5	19.5-21.5	24.0-26.0	4.2-5.2	0.03	0.03	1.2-2.0
		ER2209	0.03	0.5-2.0	0.9	21.5-23.5	7.5-9.5	2.5-3.5	0.03	0.03	0.75
Nickel-based Alloy	Ar Gas Shield	ERNiCr-3	0.1	2.5-3.5	0.5	18.0-22.0	≥67	-	0.04	0.015	-
Nickel-based Alloy	Ar Gas Shield	ERNiCrMo-3	0.1	0.5	0.5	20.0-23.0	≥58	8.0-10.0	0.02	0.015	-

1. Who are we?
We are based in Jiangsu, China, start from 2009,sell to all around the world . There are total about 101-200 people in our company.

2. How can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.What can you buy from us?
Flux Cored Wire,High Tensile FCW,Stainless Steel FCW,Stainless Steel Welding Electrodes

4. Why should you buy from us not from other suppliers?
1.Stable quality 2.Widely products range 3.Technical support 4.Sooner delivery 5.More approvals

5. What services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW;
Accepted Payment Currency:USD,EUR;
Accepted Payment Type: T/T,L/C;
Language Spoken:English,Chinese
